Wall Washer LED Strip Lights
Uniform vertical illumination for architectural walls and facades
- Even wall washing without hot spots
- Precision beam control for vertical surfaces
- Designed for architectural & commercial projects
What Is Wall Washer LED Strip?
Wall washer LED strip lights are specifically designed to illuminate vertical surfaces evenly from top to bottom.
By controlling beam angle and optical distribution, wall washer strips enhance textures, materials, and architectural rhythm rather than simply adding brightness.
Unlike standard LED strips, wall washers focus on light direction and uniformity, ensuring clean, professional visual results on walls and facades.
Wall Washer LED Strip vs Standard LED Strip
Comparison is for general reference. Product performance may vary by configuration.
| Aspect | Wall washer LED strip | Standard LED strip |
| Main purpose | Illuminate walls or facades with a strong vertical wash of light. | General accent, task, and ambient lighting along surfaces or in channels. |
| Optics and beam | Often has lenses or angled emitters to push light outward and up or down the wall. | Usually bare LEDs with wide, symmetric beam (no dedicated wall wash optics). |
| Light effect on wall | Bright gradient from top to bottom, good for highlighting textures and architecture. | Softer glow near the mounting line; wall may be lit but less dramatically. |
| Mounting orientation | Designed to be installed close to the wall with a specific aiming angle. | Flexible mounting; effect changes but not optimized for wall grazing. |
| Brightness per meter | Typically higher output per meter for strong wall illumination. | Wide range from low to high, but many are tuned for indirect or task use. |
| Typical applications | Feature walls, columns, exterior facades, gallery walls, hotel lobbies. | Under‑cabinet, coves, shelves, furniture, signage, general linear accents. |
| Installation complexity | More aiming design to avoid streaks or dark bands on walls. | Simpler: stick in channel, connect to driver, basic spacing considerations. |
| Cost and availability | Often more specialized and expensive per meter due to optics and higher power. | Very common, wide price range, many voltage and color options. |
Wall Washer LED Strip Light Key Features
High Lumen Output for Wall Washing
Engineered for strong vertical lighting effects.
Optical Lens for Uniform Beam Control
10°, 15°, 30°, 45°, and asymmetric beam options.
Multiple Options Single Color / RGB / RGBW
Suitable for architectural and decorative lighting.
Long Projection Distance
Smooth, continuous illumination for tall walls.
Indoor & Outdoor Application
Available in IP20 / IP65 / IP67.
OEM / Custom Optical Design
Customization of lenses, PCB power, CCT, and housing.
Technical Specifications
| Specification | Details |
| Power Options | 10W/m – 24W/m |
| Input Voltage | 24V / 48V |
| Optical Lens Types | 10° / 15° / 30° / 45° / Asymmetric |
| Lumen Output | 1000–2400 lm/m |
| CCT Options | 2700K–6500K |
| CRI | 80 / 90 / 95 |
| LED Type | 2835 / 3030 high-power LEDs |
| IP Rating | IP20 / IP65 / IP67 |
| Beam Uniformity | Yes, with anti-glare options |
| Max Run Length | 5m / 10m (model dependent) |
| Warranty | 3–5 Years |
Designed for Controlled Light Distribution
Wall washer LED strips are available with different beam angles to suit varying installation distances and wall heights.
Proper beam selection ensures consistent brightness from top to bottom, even on tall architectural surfaces.
- Narrow beam for close mounting
- Medium beam for standard facades
- Wide beam for large surfaces
Applications of Wall Washer LED Strip
Flexible Integration into Lighting Systems
- Compatible with standard LED drivers
- Works with DMX, DALI, and PWM control systems
- Suitable for recessed, surface mounted, or concealed installation
Customization Options
Customization is available based on project requirements and technical feasibility.
CCT & CRI Selection
LED Density & Power
Custom PCB Width & Length
Optical lens & beam angle selection
Logo & Private Labeling
Mounting & Control Methods
Certifications & Compliance
We design our LED strip products to meet international safety and environmental standards. certificates are available upon request and may vary by product model.
Need certificates for your project submission?
Contact us to request relevant documentation.
FAQ – Frequently Asked Questions
What beam angle is best for wall washing?
30° is the most common.
10°/15° are used when walls are tall or far from the strip.
Can wall washer strips replace traditional wall washer bars?
Yes, in many cases they offer:Lower cost, easier installation, better flexibility, no glare, cleaner profiles.
What mounting distance is required for wall washing?
The optimal distance depends on beam angle and wall height. We assist in selecting the correct configuration for each project.
Are certifications available for project approval?
Relevant certifications such as CE and RoHS are available upon request and may vary by product model and configuration.
What is your typical lead time for customized orders?
Lead time varies based on product type, customization level, and order volume. We will confirm production schedules after final specifications are approved.
Related Products
Need Professional Wall Washing Solutions?
Tell us about your project: wall height, installation distance, and lighting goals. and our team will recommend the optimal wall washer configuration.
